Technical Specs:
- BTU output – 250,000 BTU/H
- Based on 10°F ambient air and 60°F temp rise
- Motor
- Class 1, Div 1 explosion proof
- 1/4Hp, 1200 RPM
- 115V Single Phase
- Weight – 212LBS. (96 KG)
- Dimensions – 45-1/4″L x 28-3/4″W x 44-1/4″H (with cart)
- Fluid Lines – 1″ I.D. w/ 1″ hydraulic style quick couplers
- Optional
- Cart – Removable
- Humidistat – humidity controller, electrical in-line
-
Technical Specs:
- BTU Output: 80,187 BTU
- Based on 200°F (93°C) supply fluid and 32°F (0°C) ambient air
- 900 CFM air flow and 6 GPM fluid flow
- Blower:
- Backward inclined
- Output – 900 CFM
- Motor: 1/4 HP, 1-Speed
- Power Requirements: 120 V, single phase, 60 Hz, 3.8 A
- Controls: Thermostatic temperature control
- Weight: 90 lbs (41 kg)
- Dimensions: 23″ l x 14″ w x 34″ h
- Fluid Lines: 3/4″ I.D. w/ 3/4″ hydraulic style quick couplers
-
Technical Specs:
- BTU Output: 201,364 Btu/h
- Based on 200°F (93°C) supply fluid and 32°F (0°C) ambient air
- 2,300 CFM air flow at 1.67″ w/c 15 GPM fluid flow
- Fan: Backward inclined
- Motor: 1 HP, variable speed
- Power Requirements: 120V, single phase, 60 Hz
- Controls: Thermostatic temperature control
- Weight: 244 lbs (111 kg)
- Dimensions: 43.25″ l x 25.5″ w x 44″ h
- Fluid Lines: 300 PSI heavy-duty “Explorer Air” hose 1″ I.D. x 50′ (15.2 m)
-
Technical Specs:
- BTU Output: 201,364 Btu/h
- Based on 200°F (93°C) supply fluid and 32°F (0°C) ambient air
- 2,300 CFM air flow and 15 GPM fluid flow
- Blower:
- G Series double inlet
- Output – 2,300 CFM
- Motor: 1 HP, 3-Speed
- Power Requirements: 120V, single phase, 60 Hz, 12.7A
- Controls: Thermostatic temperature control
- Weight: 210 lbs (95 kg)
- Dimensions: 50″ l x 32″ w x 39″ h
- Fluid Lines: 1″ I.D. w/ 1″ hydraulic style quick couplers
